Portable Slump Cone Test Kit

Stock Code: PCT/SCS-C

In stock

Slump Cone Test Kit with easily transportable feature.

Concrete workability can be measured using this slump test kit. This is carried out by filling the slump cone with fresh concrete in three layers, tamping each one and levelling off to the top of the cone. The Slump Cone is then removed and the distance the concrete falls or “Slump” is measured by lifting the swivel handle which represents the high of the cone and measuring the distantance between the concrete and the handle top. This determines the slump.

This slump cone test kit is transportable with a swivel handle which is cleverly designed to house all the parts and also as a measuring reference point once the cone is removed. The cone is made from sheet steel for protection against corrosion. The kit comes with a base, slump cone and tamping rod.

Slump cone test set.
This product has been selected as part of our testing equipment range, to provide construction professionals with the best gear to assess the standard of concrete. Manufactured from sheet steel protected against corrosion, these items are strong and durable. The cone can be clamped to the base during filling and tamping then lifted to measure the specimen. When the handle is raised, the slump can be evaluated using a 22-cm scale rod, marked with long-lasting engravings on the rod at one-centimetre increments.

A very practical tool, the set is perfect for field use and, as it is seamless, it is strong, robust and reliable - able to withstand the daily wear and tear it can receive on a busy job site.The kit comes complete with a cone, tamping rod and base unit - everything you need to test samples of concrete.

Compact with a top diameter of 100mm, a base diameter of 220mm and an overall height of 300mm, this product weighs around two kilograms - which makes it easy to carry and fit in to a hardy tool bag.

Main features:

• Seamless
• Strong and robust
• Very practical
• Ideal for field use

Technical Info:

• Standards: EN 12350-2
• Series: ASTM C143
• Capacity: AASHTO T119
